Auto Spring Driven Hydraulic Hose Reel With 2 Hoses High Pressure Customized Length for Dual Oil Channel Aerial Work Vehicle
| MOQ: | 1 |
| Price: | $950/sets 1-9 sets |
| Standard Packaging: | Wooden box |
| Delivery Period: | 7-30 days |
| Payment Method: | T/T |
| Supply Capacity: | Meet large-scale orders |
Detail Information
Place of Origin
Hubei, China
Brand Name
HUATE
Model Number
HT.GKE
Working Voltage:
/
Flow Rate:
/
Warranty:
12 Months
Certificate:
/
Type:
Standard
Product Name:
Electric Dual Hydraulic Hose Reels High Pressure Spring Driven
Suit For:
Aerial Work Vehicle,Forklift,off-Road Vehicle
Material:
Carbon Steel
Max Pressure:
30Mpa
Driving Method:
Spring Dirven
Oil Channel:
Dual
Oil Pipe Size:
1/4 Inch
Package:
Carbon
Tube Retracting Method:
Automatic Retracting
Use:
Oil
Application:
Aerial Work Vehicle,Forklift,off-Road Vehicle
Highlight:
hydraulic hose reel high pressure
,dual oil channel hose reel
,aerial work vehicle hose reel
Product Description
Auto Spring Driven Hydraulic Hose Reel With 2 Hoses High Pressure Customized Length for Dual Oil Channel Aerial Work Vehicle
Product Description
Our hydraulic hose reels feature factory-lubricated one-piece power springs for safer installation and easier maintenance. Designed for cranes, forklifts, and aerial work vehicles, these durable reels are available with stainless steel latch parts as standard. Custom configurations including non-standard specifications are available upon request.
Key Features
- Heavy-duty all-steel construction for maximum durability
- Designed for two single hoses with larger diameters and extended lengths
- Available in left or right configurations with mounting flange fixation
- Self-winding mechanism powered by permanent spring force
- Full flow shaft swivels for optimal performance
- Swivel and reel ball bearings reduce torque load for smooth operation
- Corrosion-resistant sealed bearings minimize maintenance
- Adjustable guide arm accommodates wall, floor, vehicle, or overhead mounting
- Compact design maximizes space efficiency
Technical Specifications
| Specification | Value |
|---|---|
| Weight | 41 kg - 49 kg |
| Hose I.D. | 1/4" |
| Hose O.D. | 1/2" |
| Hose Length | 15.5 - 25M (Customizable) |
| Pressure | 30 Mpa |
| Hose End | 3/8" NPT(M) |
| Inlet | 3/8" NPT(M) |
| Reel Outlet | M14 x 1.5 H NPT(M) |
| Hose Included | Yes |
| Operating Temperature | -40°C to 80°C |
